Deploy Rails apps on Kubernetes cluster & no downtime

This post assumes that you have basic understanding of Kubernetes terms like pods and deployments.

Problem

We deploy Rails applications on Kubernetes frequently and we need to ensure that deployments do not cause any downtime. When we used Capistrano to manage deployments it was much easier since it has provision to restart services in the rolling fashion.

Kubernetes restarts pods directly and any process already running on the pod is terminated. So on rolling deployments we face downtime until the new pod is up and running.

Solution

In Kubernetes we have readiness probes and liveness probes. Liveness probes take care of keeping pod live while readiness probe is responsible for keeping pods ready.

This is what Kubernetes documentation has to say about when to use readiness probes.

Sometimes, applications are temporarily unable to serve traffic. For example, an application might need to load large data or configuration files during startup. In such cases, you don’t want to kill the application, but you don’t want to send it requests either. Kubernetes provides readiness probes to detect and mitigate these situations. A pod with containers reporting that they are not ready does not receive traffic through Kubernetes Services.

It means new traffic should not be routed to those pods which are currently running but are not ready yet.

Using readiness probes in deployment flow

Here is what we are going to do.

• We will use readiness probes to deploy our Rails app.
• Readiness probes definition has to be specified in pod spec of deployment.
• Readiness probe uses health check to detect the pod readiness.
• We will create a simple file on our pod with name health_check returning status 200.
• This health check runs on arbitrary port 81.
• We will expose this port in nginx config running on a pod.
• When our application is up on nginx this health_check returns 200.
• We will use above fields to configure health check in pod's spec of deployment.

Now let's build test deployment manifest.

1---
2apiVersion: v1
3kind: Deployment
4metadata:
5  name: test-staging
6  labels:
7    app: test-staging
8  namespace: test
9spec:
10  template:
11    metadata:
12      labels:
13        app: test-staging
14    spec:
15      containers:
16      - image: <your-repo>/<your-image-name>:latest
17        name: test-staging
18        imagePullPolicy: Always
19       env:
20        - name: POSTGRES_HOST
21          value: test-staging-postgres
22        - name: APP_ENV
23          value: staging
24        - name: CLIENT
25          value: test
26        ports:
27        - containerPort: 80
28      imagePullSecrets:
29        - name: registrykey
30
Copy

This is a simple deployment template which will terminate pod on the rolling deployment. Application may suffer a downtime until the pod is in running state.

Next we will use readiness probe to define that pod is ready to accept the application traffic. We will add the following block in deployment manifest.

1readinessProbe:
2  httpGet:
3    path: /health_check
4    port: 81
5  periodSeconds: 5
6  successThreshold: 3
7  failureThreshold: 2
Copy

In above rediness probe definition httpGet checks the health check.

Health-check queries application on the file health_check printing 200 when accessed over port 81. We will poll it for each 5 seconds with the field periodSeconds.

We will mark pod as ready only if we get a successful health_check count for 3 times. Similarly, we will mark it as a failure if we get failureThreshold twice. This can be adjusted as per application need. This helps deployment to determine if the pod is in ready status or not. With readiness probes for rolling updates, we will use maxUnavailable and maxSurge in deployment strategy.

As per Kubernetes documentation.

maxUnavailable is a field that specifies the maximum number of Pods that can be unavailable during the update process. The value can be an absolute number (e.g. 5) or a percentage of desired Pods (e.g. 10%). The absolute number is calculated from percentage by rounding down. This can not be 0.

and

maxSurge is field that specifies The maximum number of Pods that can be created above the desired number of Pods. Value can be an absolute number (e.g. 5) or a percentage of desired Pods (e.g. 10%). This cannot be 0 if MaxUnavailable is 0. The absolute number is calculated from percentage by rounding up. By default, a value of 25% is used.

Now we will update our deployment manifests with two replicas and the rolling update strategy by specifying the following parameters.

1replicas: 2
2minReadySeconds: 50
3revisionHistoryLimit: 10
4strategy:
5  type: RollingUpdate
6  rollingUpdate:
7    maxUnavailable: 50%
8    maxSurge: 1
Copy

This makes sure that on deployment one of our pods is always running and at most 1 more pod can be created while deployment.

We can read more about rolling-deployments here.

We can add this configuration in original deployment manifest.

1
2apiVersion: v1
3kind: Deployment
4metadata:
5  name: test-staging
6  labels:
7    app: test-staging
8  namespace: test
9spec:
10  replicas: 2
11  minReadySeconds: 50
12  revisionHistoryLimit: 10
13  strategy:
14    type: RollingUpdate
15    rollingUpdate:
16      maxUnavailable: 50%
17      maxSurge: 1
18  template:
19    metadata:
20      labels:
21        app: test-staging
22    spec:
23      containers:
24      - image: <your-repo>/<your-image-name>:latest
25        name: test-staging
26        imagePullPolicy: Always
27       env:
28        - name: POSTGREs_HOST
29          value: test-staging-postgres
30        - name: APP_ENV
31          value: staging
32        - name: CLIENT
33          value: test
34        ports:
35        - containerPort: 80
36        readinessProbe:
37          httpGet:
38            path: /health_check
39            port: 81
40          periodSeconds: 5
41          successThreshold: 3
42          failureThreshold: 2
43      imagePullSecrets:
44        - name: registrykey
45
Copy

Let's launch this deployment using the command given below and monitor the rolling deployment.

1
2$ kubectl apply -f test-deployment.yml
3deployment "test-staging-web" configured
4
Copy

After the deployment is configured we can check the pods and how they are restarted.

We can also access the application to check if we face any down time.

1
2$ kubectl  get pods
3    NAME                                  READY      STATUS  RESTARTS    AGE
4test-staging-web-372228001-t85d4           1/1       Running   0          1d
5test-staging-web-372424609-1fpqg           0/1       Running   0          50s
6
Copy

We can see above that only one pod is re-created at the time and one of the old pod is serving the application traffic. Also, new pod is running but not ready as it has not yet passed the readiness probe condition.

After sometime when the new pod is in ready state, old pod is re-created and traffic is served by the new pod. In this way, our application does not suffer any down-time and we can confidently do deployments even at peak hours.
